Reduced total cost of ownership
Eliminating all lamp-related costs, the DP4K-36BLP provides a very attractive TCO. Thanks to its unique cooling system, the projector boasts a 30,000-hour constant brightness at typical usage conditions. Its significantly higher optical efficiency results in electricity bill savings of up to 40%.
Unprecedented ease of mind
The DP4K-36BLP cuts operating expenses, reduces operational complexity, and optimizes labor cost. It increases your uptime and frees you from all lamp-related costs, administration, and maintenance.
Superior image quality
The DP4K-36BLP offers consistent DCI-compliant image quality with native 4K resolution, outstanding uniformity, and higher contrast on white and silver screens. Its light output can be dimmed to 30% of the initial brightness, enabling 2D and 3D showings from the same projector.
If you already own a Barco B-series projector you can replace your current lamp house with the unique laser phosphor retrofit module through an easy on-site upgrade.
|Brightness||35,000 lumens (typical)|
|Native contrast ratio||2,000:1 (typical)|
|Prime lenses||1.13-1.72; 1.35-1.86; 1.46-2.10; 1.65-2.60; 1.95-3.26; 2.53-4.98|
|Resolution||4,096 x 2,160|
|Long-term brightness stability||30,000 hrs @ average usage conditions|
|Dimensions (WxLxH)||Projector: 754 x 1,129 x 604 mm / 29.69 x 44.5 x 23.78 inches
Cooler: 561.5 x 738.5 x 348 mm / 22.11 x 29.07 x 13.7 inches
|Weight||Projector: 143kg (315 lb)
Cooler: 32kg (70.6 lb)
|Cooling liquid hose length||4 hoses; 0.5m, 2.5m, 5m and 8m (1.6ft/8.2ft/16.4ft/26.2 ft)|
|Vertical separation between cooler and projector||Maximum 3m (10ft) (higher or lower)|
|Power requirements||Projector: 3x 400V + N or 3x 220V
Cooler: obtains power from the projector
|Heat load (max. power)||13023 BTU/h|
|Ambient temperature||30°C (86°F) Max. (projector and cooler)|
|Ambient humidity||85% Max. (projector and cooler)|
|Power consumption||Projector (incl. cooler): 4.0 kW|
|Media server||Barco Alchemy ICMP and other IMB brands supported.|
|Noise Level||dB(A) @ 1 m:
62 dB(A) (half fan speed)
|3D systems||Active glasses systems and polarization systems on silver sceens are supported. Color separation systems (Dolby3D and 6P) are not supported.|
|Safety requirements||Class 1 risk group 3
Show safety: the customer shall take precaution for the laser safety (respect the hazard distance and separation height) according to local laser show safety regulations.
Workplace safety: the customer shall take precaution for:
